AOC Product Showcase

AOC Product Showcase

We know it's hard to stay up-to-date on new advancements in the EMSO industry. That's why we created the Product Showcase, a monthly email to AOC subscribers with the latest product updates and announcements from our industry partners. View all issues below!

Have your product featured in the next Product Showcase
Sean Fitzgerald
Sales and Client Operations Manager
| O: (703) 549-1600 ext. 222 | M: (703) 608-1799

May 2024

Abaco Systems


FMC300

Product description: Introducing the FMC300 from Abaco Systems: a game-changer in embedded computing. Ideal for SDR, EW, radar, and test & measurement, it combines high-performance ADC and DAC capabilities in a compact form, adhering to VITA 57.4 standard. Revolutionize your applications with this wideband, low-latency FMC Module.

NI — Part of Emerson

Ettus USRP X440

Product description: The Ettus USRP X440 software defined radio (SDR) device is ideal for prototyping high-performance, multichannel, wideband signal generation and analysis systems. This includes applications in radar, EW, SATCOM, and mmWave. This SDR features 8 TX and 8 RX channels with a direct sampling transceiver architecture and includes a Xilinx Zynq UltraScale+ RFSoC with a programmable FPGA.

April 2024

Erzia

ERZ-HPA-0200-2000-44

Product description: Break through the bandwidth barrier with this Wideband Amplifier from ERZIA that operates at up to 20 GHz while providing an output power of 42 dBm and a gain of 51 dB. The compact, lightweight aluminum housing features multiple mounting options, making it ideal for a variety of demanding applications.

NI — Part of Emerson

 Ettus USRP X440

Product description: The Ettus USRP X440 software defined radio (SDR) device is ideal for prototyping high-performance, multichannel, wideband signal generation and analysis systems. This includes applications in radar, EW, SATCOM, and mmWave. This SDR features 8 TX and 8 RX channels with a direct sampling transceiver architecture and includes a Xilinx Zynq UltraScale+ RFSoC with a programmable FPGA.

March 2024

Annapolis MicroSystems

64 GS/s Direct RF Small Form Factor Module

Product description: Integrating the Intel Agilex 9 Direct RF-Series FPGA, the WILDSTAR SAF1 Module is the lowest latency and highest bandwidth small form factor solution on the market. The SWaP-optimized Direct RF sampling module delivers high-performance processing and four channels each of 64 GSps, 10-bit ADCs and DACs.

Erzia

ERZ-HPA-0002-0300-42

Product description: This GaN, solid state, High Power Amplifier from ERZIA allows you to effectively target multiple types of systems over all main communication frequencies. Providing more than 15 W of output power and housed in a compact, rugged and light enclosure, it’s an ideal solution for demanding field applications.

NI — Part of Emerson

PXI Vector Signal Transceivers (VST)

Product description: The new PXIe-5842 vector signal transceiver (VST) combines a vector signal analyzer and generator into a single instrument, capable of frequency coverage up to 26.5 GHz and 2 GHz of instantaneous bandwidth. This new generation of VST provides coverage through the K band, with measurement capability that scales from simple tone generation/analysis to component testing to system-level validation.

February 2024

Annapolis MicroSystems

Versal Board Delivers Ultra-Low Latency

Product description: This Versal 3U VPX Plug-In Card (WB3XVD) is optimized for extreme low latency. It is 100GbE-enabled, SOSA-aligned, and highly rugged and reliable. Pair with an LVDS-based Mezz Card (WLDM30) for DRFM and other latency-sensitive applications. Choose from traditional RTL development, Dynamic Function eXchange (DFX) RTL, or Vitis.

Erzia

ERZ-HPA-0002-0300-42

Product description: This GaN, solid state, High Power Amplifier from ERZIA allows you to effectively target multiple types of systems over all main communication frequencies. Providing more than 15 W of output power and housed in a compact, rugged and light enclosure, it’s an ideal solution for demanding field applications.

NI — Part of Emerson

PXI Vector Signal Transceivers (VST)

Product description: The new PXIe-5842 vector signal transceiver (VST) combines a vector signal analyzer and generator into a single instrument, capable of frequency coverage up to 26.5 GHz and 2 GHz of instantaneous bandwidth. This new generation of VST provides coverage through the K band, with measurement capability that scales from simple tone generation/analysis to component testing to system-level validation.

December 2023

Abaco Systems

SBC3902

Product description: The new SBC3902 GPU-based SOSA aligned 3U VPX single board computer features the NVIDIA(r) Jetson AGX Orin(tm) SoM and delivers up to 275 TOPS of AI performance. It is part of our expanding portfolio of 100Gb Ethernet products that includes single board computers, FPGA and RFSoC boards, and switches.

Mercury

DRF3182 3U OpenVPX data conversion and FPGA processing Board

Product description: The DRF3182 3U OpenVPX board offers fast direct RF wideband data capture at the edge with heterogenous FPGA processing, explosive 51.2 GSPS A/D & D/A speeds, Ku band frequencies from 2-18 GHz and six 100 GigE interfaces with an aggregate throughput of 75 GB/sec.


Stellant Systems

Microwave Power Modules (MPMs)

Product description: Stellant’s Microwave Power Modules (MPMs) are qualified for space, ground, sea and airborne applications. They are suitable for CW/pulsed requirements and meet the power bandwidth specs for state-of-the-art microwave systems. From 2 to 50GHz, output power 40 to 300+ watts and 270 VDC, 28 VDC or 115 VAC 3-phase prime power.

Vitrek

GaGe RazorMax PCIe 16-Bit 1 GS/s PC Digitizer/Oscilloscope

Product description: Featuring unprecedented speed & resolution with four or two 16-bit input channels, 700 MHz input bandwidth, and 31 software selectable A/D sampling rates from 1 kS/s to 1 GS/s per channel. Standard 8 GB of onboard memory. PCIe data streaming rates up to 6 GB/s. PC Oscilloscope application and SDKs for C/C#, Python, MATLAB, & LabVIEW included.

November 2023

Abaco Systems

SBC3612D 3U VPX

Product description: The new SBC3612D 3U VPX single board computer aligned with the SOSA compute-intensive profile with 16-core Intel Xeon-D CPU, 100GbE data plane, and PCIe Gen 4 expansion plane features enhanced FPGA-based security, extended temperature capability, and RDMA, making it ideal for the most demanding applications including ISR, radar, and EO/IR.

Annapolis Micro

64 GS/s Direct RF Small Form Factor Module

Product description: Smaller than a golf ball in two axes, the WILDSTAR SAF1 Module is the lowest latency and highest bandwidth small form factor solution on the market. The SWaP-optimized Direct RF sampling module delivers high-performance processing and four channels each of 64 GSps, 10-bit ADCs and DACs.

Curtiss-Wright

CHAMP-FX7

Product description: The SOSA aligned CHAMP-FX7 with dual AMD® Versal™ Premium Adaptive SoC processors combined with Fabric100 technology delivers significantly higher bandwidth and lower latency processing capabilities for radar, ISR, and EW systems.

Mercury

DRF3182 3U OpenVPX direct RF and FPGA processing board

Product description: The DRF3182 3U OpenVPX board offers fast direct RF wideband data capture at the edge with heterogenous FPGA processing, explosive 51.2 GSPS A/D & D/A speeds, Ku band frequencies from 2-18 GHz and six 100 GigE interfaces with an aggregate throughput of 75 GB/sec.

October 2023

Abaco Systems

SBC3902

Product description: The new SBC3902 GPU-based SOSA aligned 3U VPX single board computer features the NVIDIA(r) Jetson AGX Orin(tm) SoM and delivers up to 275 TOPS of AI performance. It is part of our expanding portfolio of 100Gb Ethernet products that includes single board computers, FPGA and RFSoC boards, and switches.

Curtiss-Wright

Software Defined Radio and Electronic Warfare System

Product description: Curtiss-Wright’s SDR and EW system lets customers select their preferred RF tuner and software applications. The SDR is built from COTS products and consists of five 3U VPX modules, one XMC module, a power supply, backplane, and front panel assemblies housed in an MPMC-9354 chassis designed to operate in rugged environments.

Mercury

DRF3182 3U OpenVPX direct RF and FPGA processing board

Product description: The DRF3182 3U OpenVPX board offers fast direct RF wideband data capture at the edge with heterogenous FPGA processing, explosive 51.2 GSPS A/D & D/A speeds, Ku band frequencies from 2-18 GHz and six 100 GigE interfaces with an aggregate throughput of 75 GB/sec.

Vitrek

GaGe RazorMax PCIe 16-Bit 1 GS/s PC Digitizer/Oscilloscope

Product description: Featuring unprecedented speed & resolution with four or two 16-bit input channels, 700 MHz input bandwidth, and 31 software selectable A/D sampling rates from 1 kS/s to 1 GS/s per channel. Standard 8 GB of onboard memory. PCIe data streaming rates up to 6 GB/s. PC Oscilloscope application and SDKs for C/C#, Python, MATLAB, & LabVIEW included.

September 2023

Abaco Systems

IPN254

Product description: Data intensive applications demand the fastest edge computing. The IPN254 graphics and video board delivers the maximum processing performance with superior system and graphics capabilities. The GPU/CPU compute power translates into an ability to do more with less, providing more performance and throughput within the same SWaP envelope.

Annapolis Micro

64 GS/s Direct RF Small Form Factor Module

Product description: Smaller than a golf ball in two axes, the WILDSTAR SAF1 Module is the lowest latency and highest bandwidth small form factor solution on the market. The SWaP-optimized Direct RF sampling module delivers high-performance processing and four channels each of 64 GSps, 10-bit ADCs and DACs.

Curtiss-Wright

XMC-528 Security Module

Product description: The XMC-528 security module features the latest secure FPGA IP from AMD® packaged in a rugged XMC module that confidently fits into new or existing systems to add program protection. Designed for low-latency applications like EW processing systems, the XMC-528 enables secure-state-of-the-art technology to be easily tailored to program requirements.

Mercury

DRF3182 3U OpenVPX direct RF and FPGA processing board

Product description: The DRF3182 3U OpenVPX board offers fast direct RF wideband data capture at the edge with heterogenous FPGA processing, explosive 51.2 GSPS A/D & D/A speeds, Ku band frequencies from 2-18 GHz and six 100 GigE interfaces with an aggregate throughput of 75 GB/sec.

August 2023

Abaco Systems

SBC3612D 3U VPX

Product description: The new SBC3612D 3U VPX single board computer aligned with the SOSA compute-intensive profile with 16-core Intel Xeon-D CPU, 100GbE data plane, and PCIe Gen 4 expansion plane features enhanced FPGA-based security, extended temperature capability, and RDMA, making it ideal for the most demanding applications including ISR, radar, and EO/IR.

Curtiss-Wright

VPX3-E320 Ruggedized Universal Software-Defined Radio

Product description: Designed for superior durability and reliability, the VPX3-E320 3U VPX ruggedized, user-programmable software-defined radio card is ideal for low-to-medium bandwidth RF applications and aligned to The Open Group Sensor Open Systems Architecture™ (SOSA) and U.S. Army’s C5ISR/EW Modular Open Suite of Standards (CMOSS) Technical Standards.

Epiq Solutions

Sidekiq VPX410

Product description: The Sidekiq VPX410 is a SOSA aligned multichannel RF tuner solution enabling SDR applications in a 3U VPX form factor. Combining four RF receive tuners plus one RF transmit tuner in a single 3U VPX card, the Sidekiq VPX410 enables access to 18GHz RF spectrum with 1GHz of instantaneous bandwidth.

Mercury

3U OpenVPX Data Conversion and FPGA Processing Board

Product description: The DRF3182 3U OpenVPX board offers fast direct RF wideband data capture at the edge with heterogenous FPGA processing, explosive 51.2 GSPS A/D & D/A speeds, Ku band frequencies from 2-18 GHz and six 100 GigE interfaces with an aggregate throughput of 75 GB/sec.

July 2023

Abaco Systems

SBC3612D 3U VPX

Product description: The new SBC3612D 3U VPX single board computer aligned with the SOSA compute-intensive profile with 16-core Intel Xeon-D CPU, 100GbE data plane, and PCIe Gen 4 expansion plane features enhanced FPGA-based security, extended temperature capability, and RDMA, making it ideal for the most demanding applications including ISR, radar, and EO/IR.

Curtiss-Wright

VPX3-673A 3U CMOSS/SOSA Aligned A-PNT Module with Integrated Software

Product description: Rugged, high-performance Assured-PNT and central radial clock 3U VPX module with integrated Alternative RF Navigation receiver (software for US version only) and atomic clock-backed NTP/PTP timing. Aligned to the CMOSS, VICTORY, and SOSA Technical Standards, this all-in-one approach reduces complexity to provide high assurance, accurate navigation, and timing in GPS-denied environments.

Interface Concept

ComEth4682e

Product description: The ComEth4682e is a 3U VPX Gigabit Ethernet switch, based on a new generation of multi-layer Ethernet matrix for high-speed embedded interconnect applications requiring 10/25G and 40/100G connectivity. The Ethernet packet processor, managed by a dual-core ARM processor offers remarkable switching capabilities with 1G, 10G, 25, 40 and 100G Ethernet configurations.



Mercury

3U OpenVPX Data Conversion and FPGA Processing Board

Product description: The DRF3182 3U OpenVPX board offers fast direct RF wideband data capture at the edge with heterogenous FPGA processing, explosive 51.2 GSPS A/D & D/A speeds, Ku band frequencies from 2-18 GHz and six 100 GigE interfaces with an aggregate throughput of 75 GB/sec.

June 2023

Abaco Systems

IPN254

Product description: Data intensive applications demand the fastest edge computing. The IPN254 graphics and video board delivers the maximum processing performance with superior system and graphics capabilities. The GPU/CPU compute power translates into an ability to do more with less, providing more performance and throughput within the same SWaP envelope.

Annapolis Micro

64 GS/s Direct RF Card

Product description: The first COTS card with 64 GSps, 10-bit ADC and DAC capability, via a direct sampling Jariet transceiver. With a usable analog bandwidth of 36 GHz and a maximum instantaneous bandwidth of 6.4 GHz, it is targeted at demanding applications from VHF through Ka-band, and/or wide instantaneous bandwidths.



Mercury

3U OpenVPX Data Conversion and FPGA Processing Board

Product description: The DRF3182 3U OpenVPX board offers fast direct RF wideband data capture at the edge with heterogenous FPGA processing, explosive 51.2 GSPS A/D & D/A speeds, Ku band frequencies from 2-18 GHz and six 100 GigE interfaces with an aggregate throughput of 75 GB/sec.

Stellant Systems

Microwave Power Modules (MPMs)

Product description: Stellant’s Microwave Power Modules (MPMs) are qualified for space, ground, sea and airborne applications. They are suitable for CW/pulsed requirements and meet the power bandwidth specs for state-of-the-art microwave systems. From 2 to 50GHz, output power 40 to 300+ watts and 270 VDC, 28 VDC or 115 VAC 3-phase prime power.

May 2023

Abaco Systems

VP891

Product description: The VP891 is a high-performance digital signal processing board that combines both a Xilinx® Virtex UltraScale+ and Zynq® UltraScale+ FPGA technology with the flexibility of a modular FMC+ to deliver one of the most powerful and secure low-latency RF and digital processing solutions in a SOSA-Aligned 3U VPX form factor.

Curtiss-Wright

Parvus® DuraCOR® 313

Product description: The Parvus® DuraCOR® 313 low SWaP-C rugged embedded mission computer offers unparalleled modularity for add-on I/O cards and data storage in a fanless IP67-rated miniature design. Ideal for a variety of vehicle and sensor applications, the DuraCOR 313 meets MIL-STD-810G/DO-160 thermal, shock, vibration, altitude, and humidity standards.

Interface Concept

ComEth4591a

Product description: The ComEth4591a is a high performance ruggedized dual plane 3U VPX Layer 2/3 Ethernet switch developed in alignment with the SOSA™Technical Standard. It integrates two sets of independent layer 2 (Ethernet) and layer 3 switches & control processors to support physically separated Control and Data Planes for highly secured 3U VPX systems.



Mercury

3U OpenVPX Data Conversion and FPGA Processing Board

Product description: The DRF3182 3U OpenVPX board offers fast direct RF wideband data capture at the edge with heterogenous FPGA processing, explosive 51.2 GSPS A/D & D/A speeds, Ku band frequencies from 2-18 GHz and six 100 GigE interfaces with an aggregate throughput of 75 GB/sec.

April 2023

Abaco Systems

VSR8000

Product description: The VSR8000 fully rugged secure router offers significantly more ports, easier updates, and higher bandwidth than other solutions. This COTS LRU with eight 1000BASE-T ports features Juniper Networks® Junos® vSRX Virtual Firewall for high security. Update quickly via innovative connectivity options. Qualified to specifications detailed in MIL-STD-461G, MIL-STD-704F, RTCA DO-160G, and MIL-STD-810H.

Annapolis Micro

Chassis Manager / System on Module

Product description: COTS units are highly-integrated, secure, and align with SOSA™ 1.0 and VITA 46.11. Utilizes Xilinx UltraScale+ Zynq & Microsemi PolarFire FPGAs. Provides control and access to Plug-In Card JTAG and maintenance ports, CLK1 usage, network functions & optional advanced security functions.



Curtiss-Wright

CHAMP-XD3 3U VPX Intel Xeon D-1700 Processor Card

Product description: Avoid digital signal processing (DSP) bottlenecks by leveraging the CHAMP-XD3 DSP module from Curtiss-Wright. This module, developed in alignment with the Open Group Sensor Open Systems Architecture™ (SOSA) Technical Standard, balances intense computing, low power constraints, and the wide thermal range of the harshest environments.

Mercury

3U OpenVPX Data Conversion and FPGA Processing Board

Product description: The DRF3182 3U OpenVPX board offers fast direct RF wideband data capture at the edge with heterogenous FPGA processing, explosive 51.2 GSPS A/D & D/A speeds, Ku band frequencies from 2-18 GHz and six 100 GigE interfaces with an aggregate throughput of 75 GB/sec.

March 2023

Abaco Systems

VSR8000 Rugged Secure Router

Product description: The VSR8000 rugged secure router offers more ports, easier updates, and higher bandwidth than other solutions. This COTS LRU with eight 1000BASE-T ports features Juniper Networks(r) Junos(r) vSRX Virtual Firewall for high security. Update quickly via innovative connectivity options. Qualified to specifications detailed in MIL-STD-461G, MIL-STD-704F, RTCA DO-160G, and MIL-STD-810H.

Mercury

DRF3182 3U OpenVPX data conversion and FPGA processing Board

Product description: The DRF3182 3U OpenVPX board offers fast direct RF wideband data capture at the edge with heterogenous FPGA processing, explosive 51.2 GSPS A/D & D/A speeds, Ku band frequencies from 2-18 GHz and six 100 GigE interfaces with an aggregate throughput of 75 GB/sec.

Stellant Systems

Microwave Power Modules (MPMs)

Product description: Stellant’s Microwave Power Modules (MPMs) are qualified for space, ground, sea and airborne applications. They are suitable for CW/pulsed requirements and meet the power bandwidth specs for state-of-the-art microwave systems. From 2 to 50GHz, output power 40 to 300+ watts and 270 VDC, 28 VDC or 115 VAC 3-phase prime power.

Vitrek

Signatec High-Speed Signal Recording Systems

Product description: Vitrek’s Signatec brand of products provides high-speed data recording and playback solutions. This expertise in delivering real-time systems saves customers time, and eliminates uncertainties when buying gap-free recording solutions. By providing turn-key hardware and software bundles, we provide customers with a very powerful and flexible signal recording system, while minimizing the risks of self-integrated systems. Signatec systems are complete with integrated digitizers, data storage arrays, computer, and mouse driven continuous gap-free or pulsed data recording software. Customers can start recording analog signals when the system is received. All units are fully configured, and tested at maximum data rates before shipment.
